YUCHAI YC6B125-T21 ENGINE B7605-1003000/09 气缸盖及气缸盖罩总成 Cylinder Head& Cylinder Head Cover Assembly

1 330-1003190BS4 后气缸盖组件 Rear Cylinder head subassembly 1

2 338-1003021A 前气缸盖罩 Front cylinder head cover 1

3 J3200-1003022 缸盖罩垫片 Cylinder head cover gasket 2

4 330-1003180BS4 前气缸盖组件 Front Cylinder head subassembly 1

5 330-1007019C 进气门座 Intake valve seat 6

6 430-1007018 气门导管 Valve guide pipe 12

7 330-1007021 排气门座 Exhaust valve seat 6

8 B3000-1003001ASF3-386 气缸盖垫片 Cylinder head gasket 1

9 J2000-1003019 气缸盖长螺栓 Cylinder head long bolt 2

10 A3100-1003037 垫圈（二） Washer 2

11 630-1003051B 气缸盖罩（II） Cylinder head cover 1

12 J2000-1003003 气缸盖螺栓 Cylinder head bolt 8

13 J2000-1003018 气缸盖短螺栓 Cylinder head short bolt 6

14 J2000-1003014 缸盖短螺栓（II） Cylinder head short bolt 6

15 6105QA-1003017D 垫圈 Washer 6

16 J2000-1003002 气缸盖长螺栓（I） Cylinder head long bolt 4

17 6105QA-1003088 气缸盖定位销套 Cylinder head dowel pin sleeve 4

18 B75J0-1002141 吊耳 Lifter 2

19 340-1013007 机油管夹 Oil pipe clip 1

20 B7605-1003048A 通气软管 Ventilation hose 1

21 Q67638 环箍 38 Loop hoop 38 1

22 D0300-1003260 上呼吸器组件 Upper breather subassembly 1

23 Q5002040 销 2X40 Pin 1

24 330-1003053 密封圈 Sealing ring 1
