SDLG LG938L LG956L LG958LWHEEL LOADER SPARE PARTS:

电气系统 ELECTRIC SYSTEM

1 29370009571 启动马达线 LINE FROM SWITCH TO MOTOR Y 1

2 4011000461 螺栓GB16674-M8*16EpZn-8.8 BOLT GB16674-M8*16EpZn-8.8 N 16

3 29370014291 电瓶线A50*350 BATTERY WIRE A50*350 Y 1

4 4130000427 电源开关K01K18-A POWER SWITCH K01K18-A Y 1

5 29370014261 电瓶线P50*150 BATTERY WIRE P50*150 Y 1

6 4130000057 蓄电池6-QW-120B BATTERY 6-QW-120B Y 2

7 29370013101 蓄电池串联线 BATTERY CABLE Y 1

8 29310011841 卡子胶条 DIP RUBBER BAR Y 2

9 29370015301 继电器保护盒 RELAY PROTECT BOX Y 1

10 4014000024 螺钉GB818-M6*10EpZn-4.8 SCREW GB818-M6*10EpZn-4.8 N 4

11 4015000207 垫圈GB97.1-6EpZn-300HV WASHER GB97.1-6EpZn-300HV N 6

12 4015000035 垫圈GB93-6-65Mn WASHER GB93-6-65Mn N 6

13 29370015291 继电器固定板 RELAY FIXATION PLANT Y 1

14 4130000694 接触器MZJ-100A/006 CONTACTOR MZJ-100A/006 Y 2

15 4014000061 螺钉GB818-M4*10EpZn-4.8 SCREW GB818-M4*10EpZn-4.8 N 4

16 4015000135 垫圈GB97.1-4EpZn-300HV WASHER GB97.1-4EpZn-300HV N 4

17 4015000033 垫圈GB93-4-65Mn WASHER GB93-4-65Mn N 4

18 4190000020 扎丝LG13-ZS4*250 CLIP LG13-ZS4*250 Y 84

19 26370001911 管夹 CLAMP Y 5

20 4130000009 双音盆形喇叭DL125-24V ELECTRIC HORN DL125-24V Y 1

21 4011000152 螺栓GB16674-M6*10EpZn-8.8 BOLT GB16674-M6*10EpZn-8.8 N 2

22 4130000542 前左组合灯LFLDH4-24V LEFT FRONT HEAD LAMP LFLDH4-24V Y 1

23 29370014021 前车架线束 FRONT BODY WIRING HARNESS Y 1

24 4130000543 前右组合灯LFRDH4-24V RIGHT FRONT HEAD LAMP LFRDH4-24V Y 1

25 29370015591 启动继电器固定板 FIXED PLATE OF STARTUP RELAY Y 1

26 4130000874 启动继电器SW030A3509-2 ENABLE RELAY SW030A3509-2 Y 1

27 4014000026 螺钉GB818-M6*16EpZn-4.8 SCREW GB818-M6*16EpZn-4.8 N 2

28 4130000329 隔膜式压力开关0166-40404-1-016 PRESS SWITCH 0166-40404-1-016 Y 1

29 4130000326 接近开关WEK200-IV ADJACENT SWITCH Y 1

30 4130000278 隔膜式压力开关310-LGK DISSEPIMENT PRESSURE SWITCH310-LGK Y 1

31 29370015121 后车架线束 BODY WIRING HARNESS Y 1

32 4130000213 后尾灯LRTD－24V REAR LAMP LRTD－24V Y 2

33 4130000544 后大灯SPH4-1031 REAR LARGE LAMP SPH4-1031 Y 2

34 29370009531 后罩线束 COVER HARNESS Y 1

35 4130000615 前照灯QZD-1 FORWARD LIGHTING QZD-1 Y 4

36 4130000121 倒车蜂鸣器KSHM-12F4 ANNUNCIATOR KSHM-12F4 Y 1

37 29370015141 仪表台线束总成 PANEL HARNESS ASSEMBLY Y 1

38 4130000869 中间继电器024-1Z6GD2 AUXILIARY RELAY 024-1Z6GD2 Y 6

39 4014000048 螺钉GB818-M5*12EpZn-4.8 SCREW GB818-M5*12EpZn-4.8 N 6

40 4015000110 垫圈GB97.1-5EpZn-300HV WASHER GB97.1-5EpZn-300HV N 6

41 4015000034 垫圈GB93-5-65Mn WASHER GB93-5-65Mn N 6

42 29370015351 仪表盘总成Y956CAT PANEL ASSEMBLY Y956CAT Y 1

43 29370014681 仪表台总成 INSTRUMENT DESK ASSEMBLY N 1

44 4130000498 侧边单框架JK931-01CKJ SIDE FRAME JK931-01CKJ Y 6

45 4130000496 盖板JK931-01GB CAP JK931-01GB Y 13

46 4130000497 中间单框架JK931-01ZKJ MIDDLE FRAME JK931-01ZKJ Y 7

47 4130000060 手制动开关LA39-01Z HAND BRAKE SWITCH LA39-01Z Y 1

SDLG L956F WHEEL LOADER SPARE PARTS:

1 4011001423 螺栓GB16674.1-M6*10f1Znyc-8.8-480 Bolt 2

2 4130002557 盆型喇叭DL125-100L-01 Horn Y

3 4130000542 前左组合灯LFLDH4-24V Lamp Y 1

4 29410001961 接近开关过渡线束 Cable hattess Y 1

5 29410001701 前车架线束 Wiring harness Y 1

6 4011001297 螺栓GB16674.1-M8*16f1Znvc-8.8-48 Screw Y 9

7 4190001838 扎丝RTGB-370HD-S Cibletie Y 5

8 4130000543 前右组合灯LFRDH4-24V Lamp 1

9 4130002556 盆型喇叭DL125-100H-01 Horn

10 4130001028 接近开关I7-D10B1/DC Fosition switch Y 2

11 4130001006 CLIP 1027-003-1200 alip Y 2

12 29140016461 举升限位支架 Bracket Y

13 4011001241 螺栓GB5783-M12*25f1Znuc-8.8-480 Screw Y 2

14 4015000128 华图GB97.1-12f1Znvc-300HV-480 Washer Y 2

15 4041002411 管夹LGB169-A15*10 Clamp Y 3

16 4041002410 管夹LGB169-112*10 Clamp 6
