SDLG RS8200 ROAD ROLLER SPARE PARTS

震动液压系统 HYDRAULIC VIBRATORY SYSTEM

1 4120005307 软管20411-26-10TZ/20491-26-10TZXFC686- Hose 1

2 28120005251 振动泵总成 Piston pump N 1

3 4120006163 软管87612Y-16-122/87692Y-16-12Z*GH493 Hose assemb ly Y 1

4 4120005306 软管20411-36-16TZ/20491-36-16TZXFC686- Hose 1

5 4120006162 软管87612Y-16-12Z/87692Y-16-12Z*GH493- Hose assembly 1

6 4015000168 垫圈GB97.1-12EpZn-300HV Washer Y 28

7 4120003278 外六角螺栓7/16-14UNC*45-EpZn Bolt Y 16

8 4120001099 法兰总成M2M2HK-16 Flange half 4

9 4011000197 螺栓GB5783-M12*25EpZn-8.8 Bolt 6

10 4011000054 螺栓GB5782-M12*120EpZn-8.8 Bolt 3 r

11 4013000011 螺母GB6170-M12EpZn-8 Y 6 NutY

12 28120002531 盖板 Fixation plate 1

13 28120002551 橡胶板 Rubber clamp 2

14 28120002541 橡胶板 Rubber clamp Y 1

15 28120004311 固定板 Plate 1 r

16 4120001850 三通接头EL18LOMDA3C Three way nipple 1

17 28120004931 管夹板 Plate Y 6

18 28120005121 管夹 Clamp Y

19 28120005131 压板 Plate 2

20 4011000082 螺栓GB5783-M10*25EpZn-8.8 Bolt Y 4

21 4015000162 垫圈GB97.1-10EpZn-300H Washer Y 4

22 4015000072 垫圈GB97.1-8EpZn-300HV Washer Y 8

23 28120004981 管夹板 Plate Y 1

24 4013000033 螺母GB6170-M8EpZn-8 Nut Y 8 Y

25 4011000681 螺栓GB5782-M8*80EpZn-8.8 Screw 4

26 4120005305 软管20411-26-10TZ/20491-30-10TZXFC686- Hose Y 1

27 4120000264 接头GE18L7/8UNFOMDA3C Nipple Y 1

28 4120000263 振动马达总成90M055 Hydraulic motor 1

29 4011000091 螺栓GB5783-M12*40EpZn-8.8 Bolt Y 4

30 28120002011 厚垫圈12 Washer 4

31 28120005471 密封垫 Gasket Y 1

32 4120003897 堵头9C-36 Nipple Y 1

33 28120004971 法兰盖板 Cover Y 1

34 4030000164 0形圈GB3452.1-60.0*3.55G 0-ring Y 1

35 4120000145 过渡接头EW28LOMDA3C Nipple 1

36 4120004835 直通接头1CH-36-33 Nipple 1 Y

37 28110006611 堵头 Y 1 Plug

38 4120002598 三通接头ET18LOMDCF Three way nipple 1

39 28120006651 压板 Plate Y 1

40 4030000017 0形圈GB1235-75*3.1 O-ring 1

41 4120004899 液压油箱吸油滤芯WU20x100-1 Filter insert Y 1
