SDLG LG936L LG938L LIFT ARM CYLINDER 371368 动臂油缸

1 4120000867102 丝座HSGF-125/70*771-1 RETAINER N 1

2 4120000867103 活塞杆HSGF-125/70*771-2 PISTON ROD Y 1

3 4120000867101 密封件包 SEALING MEMBER AGGREGATE Y 1

4 4014000153 螺钉GB70.1-M6*30EpZn-10.9 SCREW GB70.1-M6*30EpZn-10.9 N 4

5 4015000035 垫圈GB93-6-65Mn WASHER GB93-6-65Mn N 4

6 4120000867101 密封件包 SEALING MEMBER AGGREGATE Y 1

7 4120000867101 密封件包 SEALING MEMBER AGGREGATE Y 1

8 4120000867118 挡环 HSGK-125/70*771-3 SPCER RING N 1

9 4120000867119 钢丝挡圈 GB/T895.1-86 STEEL WIRE RING SNAP N 1

10 4120000867101 密封件包 SEALING MEMBER AGGREGATE Y 1

11 4120000867105 导向圈HSGF-125/70*771-4 ORIENTED SHEATH N 1

12 4120000867101 密封件包 SEALING MEMBER AGGREGATE Y 1

13 4120000867101 密封件包 SEALING MEMBER AGGREGATE Y 1

14 4120000867101 密封件包 SEALING MEMBER AGGREGATE Y 1

15 4120000867101 密封件包 SEALING MEMBER AGGREGATE Y 2

16 4120000867108 缸体HSGF-125/70*771-5 CYLINDER BODY N 1

17 4120000867101 密封件包 SEALING MEMBER AGGREGATE Y 1

18 4120000867101 密封件包 SEALING MEMBER AGGREGATE Y 2

19 4120000867101 密封件包 SEALING MEMBER AGGREGATE Y 2

20 4014000238 螺钉GB70.1-M8*20-8.8 SCREW GB70.1-M8*20-8.8 N 1

21 4120000867111 活塞HSGF-125/70*771-6 PISTON N 1

22 4120000867121 衬套 HSGK-125/70*771-7 BUSHING Y 1

23 4120000867101 密封件包 SEALING MEMBER AGGREGATE Y 1
