SDLG LG953 WHEEL LOADER

行星排 330101 PLANET ROW

1 4011000772 螺栓GB5783-M14*40-8.8 BOLT GB5783-M14*40-8.8 N 8

2 4015000027 垫圈GB93-14-65Mn WASHER GB93-14-65Mn N 8

3 4110000184070 中盖 403003A COVER 403003A Y 1

4 4110000184071 一档油缸体 403004 CYLINDER BODY Y 1

5 4110000184072 固定板 403023 FIX PLATE 403023 Y 1

6 4030000011 O形圈GB1235-20*2.4 O-RING GB1235-20*2.4 Y 1

7 4110000184073 外密封环 403006A PACKING RING Y 2

8 4110000184074 内密封环 403010A INTERNAI SEAL RING 403010A Y 1

9 4110000184075 一档活塞体 403008A PISTON Y 1

10 4110000184076 一档内齿圈 403222 INTERNAL GEAR-RING Y 1

11 4110000184077 倒档一档主动片总成 403012-013 REVERSE FIRST SPEED DRIVE DISK ASS’Y 403012-013 Y 8

12 4110000184078 倒档一档从动片 403011 REVERSE FIRST SPEED DRIVEN DISK 403011 Y 8

13 4011000777 螺栓GB5783-M10*30-8.8 BOLT GB5783-M10*30-8.8 N 4

14 4015000025 垫圈GB93-10-65Mn WASHER GB93-10-65Mn N 4

15 4110000184079 直接档连接盘 403225 CONNECTING DISK 403225 Y 1

16 4015000024 挡圈GB894.1-90-65Mn RETAINNER RING GB894.1-90-65Mn N 1

17 4021000180 轴承GB277-50210 BEARING GB277-50210 Y 1

18 4110000184080 太阳轮 403226 GEAR-SUN 403226 Y 1

19 4110000184081 止动片 403224 STOP PLATE 403224 Y 1

20 4110000184082 一档行星架 403223 PLANET CARRIER Y 1

21 4110000184083 卡圈 403220 RETAINER RING 403220 Y 1

22 4110000184084 倒档内齿圈 403216 REVERSE RANGE GEAR-RING 403216 Y 1

23 4110000184085 摩擦片隔架总成 403014-15 FRAME ASSEMBLY 403014-15 Y 1

24 4110000184086 倒档行星架 403213 CARRIER OF REVERSE ASS’Y 403213 Y 1

25 4110000184087 止动垫圈 403215 THRUST WASHER 403215 Y 4

26 4015000036 垫圈GB93-8-65Mn WASHER GB93-8-65Mn N 4

27 4011000775 螺栓GB5783-M18*14-8.8 BOLT GB5783-M18*14-8.8 N 4

28 4110000184088 内密封环 403020A INTERNAI SEAL RING 403020A Y 1

29 4110000184089 倒档活塞体 403018A PISTION 403018A Y 1

30 4021000011 滚动轴承GB276-6010 BALL BEARIN GB276-6010 Y 1

31 4110000184090 一档行星轴 403227 FIRST SPEED PLANET SPINDLE Y 4

32 4110000184091 垫片 403217 SPACER 403217 Y 16

33 4110000184092 隔离套 403219 ISOLATED BUSHING 403219 Y 16

34 4090000001 滚针GB309-4*35-GCr15 ROLLER GB309-4*35-GCr15 Y 176

35 4110000184093 行星轮 403218 PLANET GEAR 403218 Y 8

36 4110000184094 弹簧销轴 403016 SPRING PIN 403016 Y 15

37 4110000184095 弹簧 403017 SPRING 403017 Y 15

38 4110000184096 倒档行星轴 403221 REVERSE PLANET SPINDLE 403221 Y 4
