YUCHAI YC6J125-T21 ENGINE

B7615-1002000/03 气缸体总 Cylinder Block Assembly

1 330-1002064B 气缸套 Cylinder liner 6 易损件 EWP

2 A3000-1002063 气缸套封水圈 Cylinder liner water seal 6 易损件 EWP

3 A3000-1002063B 气缸套封水圈 Cylinder liner water seal 6 易损件 EWP

4 330-1002114 气缸体 Cylinder block 1

330-1002114* 气缸体组件 Cylinder block subassembly 1

5 YC208-B01600F O 形圈 2.65×16 O-ring 1

6 6105Q-1002067 主油道密封塞 Main oil passage sealing plug 1

7 6105Q-1002081A 油标尺套管 Oil dipstick sleeve 1

8 1640H-1028140 油标尺构件 Oil dipstick part 1

9 B0100-1002104 铝堵φ10×10 Aluminum blockage 1

10 330-1002150 调压阀总成 Pressure regulator assembly 1

11 Q618B02 螺塞 NPT1/4 Screw plug 2

12 Q618B01 螺塞 NPT1/8 Screw plug 2

13 330-1002065D 挺杆室盖 Tappet housing cover 2

14 Q40108 垫圈 8 Washer 8 16

15 Q40308 垫圈 8 Washer 8 19

16 Q150B0825 螺栓 M8X25 Bolt M8X25 8

17 Q150B0822 螺栓 M8X22 Bolt M8X22 8

18 330-1002066C 挺杆室盖垫片 Tappet housing gasket 2

19 J3200-1002062 凸轮轴端盖垫片 Crankshaft end cover washer 1 易损件 EWP

20 6105Q-1002110 后主油道堵塞 Rear main oil galley plug 1

21 630-1002061 凸轮轴端盖 Camshaft end cover 1

22 Q1840816 螺栓 M8×16 Bolt 3

23 330-1002021B 主轴承螺栓 Main bearing bolt 12

24 330-1002018B 前主轴承盖螺栓 Front main bearing cover bolt 2
