SDLG LG918 WHEEL LOADER SPARE PARTS

后车架总成 REAR FRAME ASSEMBLY

1 29270008621 副车架 OSCILLATING FRAME Y 1

2 29270006582 副车架前油管 FRONT OIL TUBE OF SOCILLATING FRAME Y 1

3 29250000311 管卡 Plate Y 2

4 4015000035 垫圈GB93-6-65Mn WASHER GB93-6-65Mn N 4

5 4014000024 螺钉GB818-M6*10EpZn-4.8 SCREW GB818-M6*10EpZn-4.8 N 4

6 4030000065 油杯JB7940.1-M10*1 GREASE NIPPLE JB7940.1-M10*1 Y 4

7 29270006601 副车架后油管 REAR OIL TUBE OF SOCILLATING FRAME Y 1

8 29270009101 走线胶套 RUBBER SLOEVE Y 2

9 4011000087 螺栓GB5783-M12*20EpZn-8.8 BOLT GB5783-M12*20EpZn-8.8 N 2

10 4040000001 垫圈LGB001-12 WASHER LGB001-12*45*6 Y 2

11 29270006651 锁定杆前销轴 FRONT PIN OF MOUNT BAR Y 1

12 29270000081 卡环 HOLDING RING Y 1

13 29270006671 锁定杆 MOUNT BAR Y 1

14 29270006681 锁定杆后销轴 REAR PIN OF MOUNT BAR Y 1

15 4016000194 开口销GB91-8*50EpZn-Q235A SPLIT PIN GB91-8*50EpZn-Q235A Y 1

16 29250007971 前转向销轴 PIN Y 2

17 29270006701 盖板 COVER PLATE Y 2

18 4011000102 螺栓GB5783-M8*16EpZn-8.8 BOLT GB5783-M8*16Ep

19 29270006711 机油滤清器支架 BRACKET Y 1

20 4011000447 螺栓GB16674-M10*20EpZn-8.8 BOLT GB16674-M10*20EpZn-8.8 N 2

21 29250000291 通油螺栓 BOLT Y 2

22 29250000301 垫片 WASHER Y 4

23 29270006741 套 BUSH Y 2

24 29270006751 调整垫片 ADJUST SPACER Y 2

25 29270006761 调整垫片 ADJUST SPACER Y 2

26 29270006771 调整垫片 ADJUST SPACER Y 2

27 4043000143 销轴LGB301-40*70R*110-40Cr PIN LGB301-40*70R*110-40Cr Y 2

28 4011000081 螺栓GB5783-M10*20EpZn-8.8 BOLT GB5783-M10*20EpZn-8.8 N 2

29 4040000008 垫圈LGB001-10 WASHER LGB001-10 Y 2

30 29260014181 后车架 rear frame Y 1

31 4015000256 垫圈GB96.1-8EpZn-300HV WASHER GB96.1-8EpZn-300HV N 8

32 4043000326 垫片LGB303-35*60*1 WASHER LGB303-35*60*1 Y 4

33 4043000327 垫片LGB303-35*60*2 WASHER LGB303-35*60*2 Y 4
