SDLG LG936L TRANSMISSION ASSEMBLY A303 变速箱总成

SDLG LG956L TRANSMISSION ASSEMBLY A305 变速箱总成

1 4021000020 滚动轴承GB276-6211 BEARING GB276-6211 Y 1

2 3030900094 轴齿轮 SHAFT GEAR Y 1

3 4021000019 滚动轴承GB276-6210N BEARING GB276-6210N Y 2

4 4015000024 挡圈GB894.1-90-65Mn RETAINNER RING GB894.1-90-65Mn N 2

5 29050000071 轴承套 BEARING COVER Y 1

6 4021000012 滚动轴承GB276-6012 BEARING GB276-6012 Y 1

7 29050000081 驱动轴 DRIVE SHAFT Y 1

8 4022000001 键GB1096-14*36-45 KEY GB1096-14*36-45 Y 1

9 3030900100 转向泵驱动齿轮 DRIVE GEAR OF STEERING PUMP Y 1

10 2030900027 三轴总成 3RD SHAFT ASS’Y N 1

11 2030900026 四轴总成（1） 4TH SHAFT ASS’Y（Ⅰ） N 1

12 29050011341 密封垫 SEALING SPACER Y 1

13 29050011351 密封垫 SEALING SPACER Y 1

14 29050012592 输出轴总成 OUTPUT SHAFT ASS’Y N 1

15 4120000345 螺塞Q/ZB286-ZG1/2"-Q235A PLUG SCREW Q/ZB286-ZG1/2"-Q235A Y 1

16 3030900102 螺塞 PLUG SCREW Y 1

17 3030900090 中盖 COVER Y 1

18 4015000027 垫圈GB93-14-65Mn WASHER GB93-14-65Mn N 8

19 3030900089 中盖螺栓 BOLT Y 8

20 29050011321 密封垫 SEALING SPACER Y 1

21 29050011331 密封垫 SEALING SPACER Y 1

22 2030900019 四轴总成(2) 4TH SHAFT ASS’Y（Ⅱ） N 1

23 3030900091 端盖 END COVER Y 1

24 4015000025 垫圈GB93-10-65Mn WASHER GB93-10-65Mn N 39

25 4011000017 螺栓GB21-M10*30EpZn-8.8 BOLT GB21-M10*30EpZn-8.8 N 34

26 3010900185 箱体 CASE Y 1

27 4011000174 螺栓GB21-M10*70EpZn-8.8 BOLT GB21-M10*70EpZn-8.8 N 5

28 4030000011 O形圈GB1235-20*2.4 O-RING GB1235-20*2.4 Y 1

2030900027 三轴总成 3RD SHAFT ASS’Y

1 4021000013 滚动轴承GB276-6016 BALL BEARING GB276-6016 Y 1

2 3030900110 旋转油封 SEAL Y 1

3 3030900178 输入二级齿轮 2nd STAGE INPUT Y 1

4 3030900111 旋转油封 SEAL Y 1

5 4021000040 滚动轴承GB301-51111 THRUST BALL BEARING GB301-51111 Y 1

6 3030900177 输入一级齿轮 1ST STAGE GEAR INPUT Y 1

7 4021000023 滚动轴承GB276-6311 BEARING GB276-6311 Y 1
